Clamp, Uses 8 Inserts, TAG Inserts, 8 Tooth, Straight Teeth
| Connection Type | Arbor |
|---|---|
| Cutting Width (mm) | 2.00 |
| Maximum Depth of Cut (mm) | 19.00 |
| Hole Diameter (Mm) ( - 0 Decimals) | 22.00 |
| Cutter Diameter (mm) | 80.00 |
| Shank Diameter (mm) | 22.00 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Clamp |
| Number Of Cutter Inserts | 8 |
| Compatible Insert Style | TAG |
| Compatible Insert Size Code | 2 |
| Tooth Type | Straight |
| Series | TGSF |
| Toolholder Style | TGSF |
| Hub Diameter (mm) | 40.00 |
| Cutting Radius (Fractional Inch) | 1/64 |
| Maximum RPM | 1000 |
| Tool Application | Milling |
| Minimum Cutting Width (Decimal Inch) | 0.0787 |
| Minimum Cutting Width (Inch) | 5/64 |
| Maximum Cutting Width (mm) | 2.05 |
| Minimum Cutting Diameter (mm) | 80.00 |
| Lead Angle | 90 |
| UNSPSC Code | 23241629 |
| Maximum Body Diameter (mm) | 40.00 |
| Cutter Body Width (mm) | 1.65 |
| Manufacturers Catalog Number | TGSF 80-2-22KR |
| Number Of Teeth | 8 |
| Complete Insert Compatibility | TAG N2C |
| Country of Origin | Israel |
| MSC Number | MSC# 45387396 |
