Uses (4) 3M AXKT 1304... Inserts, 4" OAL
| Cutting Diameter | 1 |
|---|---|
| Overall Length (Decimal Inch) | 4.0000 |
| Overall Length (Inch) | 4 |
| Maximum Depth of Cut (Decimal Inch) | 0.9600 |
| Cutter Style | 3M AXK-13 |
| Shank Type | Weldon Flat |
| Shank Diameter (Decimal Inch) | 1.0000 |
| Shank Diameter (Inch) | 1 |
| Insert Holding Method | Screw |
| Tool Material | Solid Carbide |
| Series | Mill2000 |
| Flute Type | Helical |
| Shank Length (Decimal Inch) | 2.6200 |
| Head Length (Decimal Inch) | 1.38 |
| Tool Application | Milling |
| Standards | ISO 9001:2008; AS 9100; OSHAS18001:2007; ISO 50001; ISO 14001:2004 |
| Rake | Positive |
| Insert Compatibility | 3M AXKT 1304... |
| UNSPSC Code | 27112803 |
| Number Of Flutes | 2 |
| Number Of Cutter Inserts | 4 |
| Coolant Through | No |
| Country of Origin | Israel |
| MSC Number | MSC# 33011297 |
