Uses (2) Inserts, Through Coolant, 2 mm OAL
| Cutting Diameter | 1.2598 in |
|---|---|
| Cutting Diameter (mm) | 32.00 |
| Overall Length (Decimal Inch) | 7.8740 |
| Overall Length (mm) | 2.00 |
| Maximum Depth of Cut (mm) | 15.80 |
| Maximum Depth of Cut (Decimal Inch) | 0.6220 |
| Cutter Style | HM90 EAL-16 |
| Shank Type | Cylindrical |
| Shank Diameter (Decimal Inch) | 1.2598 |
| Shank Diameter (mm) | 32.00 |
| Insert Holding Method | Screw |
| Maximum Ramping Angle | 22.4 |
| Series | Helialu |
| Lead Angle | 90 |
| Shank Length (mm) | 120.00 |
| Head Length (Decimal Inch) | 3.1496 |
| Head Length (mm) | 80.00 |
| Maximum RPM | 45643 |
| Tool Application | Milling |
| Standards | ISO 9001:2008; AS 9100; OSHAS18001:2007; ISO 50001; ISO 14001:2004 |
| UNSPSC Code | 27112803 |
| Number Of Cutter Inserts | 2 |
| Coolant Through | Yes |
| Country of Origin | Israel |
| MSC Number | MSC# 07639818 |
