Uses (4) T290 LN.T 0502 Inserts, Through Coolant, 80 mm OAL
| Cutting Diameter (mm) | 16.00 |
|---|---|
| Overall Length (mm) | 80.00 |
| Maximum Depth of Cut (mm) | 5.00 |
| Cutter Style | T290 ELN-05 |
| Shank Type | Cylindrical |
| Shank Diameter (mm) | 16.00 |
| Insert Holding Method | Screw |
| Tool Material | Solid Carbide |
| Series | SumoMill |
| Lead Angle | 90 |
| Shank Length (mm) | 58.00 |
| Head Length (mm) | 22.00 |
| Tool Application | Milling |
| Standards | ISO 9001:2008; AS 9100; OSHAS18001:2007; ISO 50001; ISO 14001:2004 |
| Insert Compatibility | T290 LN.T 0502 |
| UNSPSC Code | 27112803 |
| Number Of Flutes | 4 |
| Number Of Cutter Inserts | 4 |
| Coolant Through | Yes |
| Country of Origin | Israel |
| MSC Number | MSC# 01070846 |
