KPSE 26C 2620 PIN RECP
| Item | Pin & Sleeve Receptacle |
|---|---|
| Shell Color | Olive Drab |
| Insert Material | Neoprene |
| Shell Plating | Olive Drab Cadmium |
| Orientation | Straight |
| Shell Material | Aluminum Alloy |
| Connector Type | Circular |
| Endbell Type | Cable Clamp |
| Mounting Type | Cable |
| Shielding | Yes |
| Contact Style | Pin |
| Operating Temperature °F (°C) | -67 to +257 (-55 to +125) |
| Connector Style | Receptacle |
| Operating Voltage DC | 850 |
| Sealing | IP67 |
| Operating Voltage AC V RMS Max | 600 |
| Contacts Supplied | No |
| No. of Contacts | 26 |
| Grommet & Seals Material | Neoprene |
| Rotation Angle | 338 |
| Insert Rotation/Keying | Z |
| Contact Mating Life | 500 |
| Insert Arrangement | 16 to 26 |
| Termination Method | Crimp |
| Crimp Wire Gauge | 20, 22, 24 |
| Service Rating | I |
| Contact Size | 26#20 |
| Package Quantity | 1 |
