Control Ball Valve, 3-Way, 185 Coefficient
| Item | HVAC Control Ball Valve |
|---|---|
| Coefficient of Volume | 185 |
| Width | 13 in |
| For Use With | Mfr. No. M9000 |
| Height | 15 in |
| Depth | 15 in |
| Safe Working Water PSI | 250 psi |
| Material | Brass, Stainless Steel |
| Valve Only/Actuator Included | Valve Only |
| Connection Type | Flanged |
| Max. Water Temp. | 284 Degrees F |
| Safe Working Steam PSI | 25 |
| Connection Size | 4 in |
| Closeoff Pressure | 50 psi |
| Valve Type | 3-Way |
| Application | Control of Hot/Chilled Water |
| Actuator Control Pressure - Minimum | Not Applicable |
| For Media | Water-Glycol Solution to 50%, Water, Steam |
| Actuator Return Action | Not Applicable |
| Leakage Rate | 1 % |
| Flow Characteristic | Equal Percentage, Linear |
| Seat Material | Graphite-Reinforced PTFE |
| Body Material | Brass |
| Actuator Type | Not Applicable |
| Specific Valve Action | Stem Down to Close |
| Overall Length | 13 in |
| Ball Material | Stainless Steel |
| Overall Height | 15 in |
| Actuator Control Pressure - Maximum | Not Applicable |
| Body Pattern | Three-Way |
| Gasket Material | EPDM |
| Port Connection Type | Flanged |
| ANSI Rating | ANSI Leakage Class IV |
| Port Types Included | Bypass, Control |
| Bypass Port Coefficient of Volume (Cv) | 190 |
| Trim Material | Stainless Steel |
| Disk Material | Polyphthalamide Resin |
| Operating Temperature - Minimum | 0 deg F |
| Overall Depth | 15 in |
| Manufacturer Series | VG1000 |
| Includes Actuator | Actuator Not Included |
| Valve Style | Mixing |
| Coefficient of Volume (Cv) | 185 |
| Rangeability | 500:1 |
| Actuator Control Signal | Not Applicable |
| Actuator Input Voltage | Not Applicable |
| Operating Temperature - Maximum | 284 deg F |
| Includes Characterizing Disk | Disk Included |
| Port Connection Size | 4 in |
| Stem Material | Stainless Steel |
| Close-Off Pressure | 50 psi |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
