Digital Wall Item: Line Voltage Thermostat, Duct Mount
| Voltage | 14 to 30V DC, 20 to 30V AC |
|---|---|
| Sensor Type | 1,000 ohm |
| Display Type | LED |
| Switch Type | DIP |
| For Use With | Any BAS/DDC System |
| Connection | Screw Terminals |
| Type | Duct Mount |
| Item | Line Voltage Thermostat |
| Features | Controller Configuration Dip Switch, Manual Override Pushbutton, Power Supply Selection Switch, User-Selectable Humidity Output, Warmer/Cooler Setpoint Dial |
| Dimensions | 3.2 in x 3.2 in x 1.4 in |
| Agency Compliance | UL |
| Includes | Screw Terminal Block Terminations that Provide Flexibility for Field Wiring |
| Standards | Energy Management Equipment, File E107041, CCN PAZX, UL Listed, UL Listed 916 |
| Overall Length | 1-1/4 in |
| Manufacturers Warranty Length | 3 yr |
| Minimum Storage Temperature | -40 Degrees F |
| Relative Humidity Range | 0 to 100% |
| Output | 0 to 10V DC, 0 to 5V DC |
| Sensing Element Type | Platinum |
| Temperature Accuracy | +/-0.35 deg F |
| Enclosure Material | Thermoplastic |
| Electrical Connection Type | Screw Terminal |
| Maximum Storage Temperature | 140 Degrees F |
| Series | HE-6800 |
| Overall Height | 3-1/4 in |
| Power Required | 18 to 25 mA at 20 to 30V AC, 4.5 to 7.5 mA at 14 to 30V DC |
| RH Sensor | Temperature |
| Includes Power Supply | Yes |
| Overall Width | 3-1/4 in |
| Relative Humidity Accuracy | +/-3% of Full Scale |
| Minimum Operating Temperature | 32 deg F |
| Maximum Operating Temperature | 131 deg F |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
