Humidity Controller, Surface or DIN rail, 10% to 90%, SPDT, 120 to 240V AC
| Voltage | 120 to 240V AC |
|---|---|
| Differential | 2 to 10% RH |
| Mounting Location | Surface or DIN rail |
| Switch Type | SPDT |
| Color | Gray |
| Height | 5 in |
| Height (In.) | 5 |
| Mounting | DIN |
| Depth (In.) | 3 |
| Agency Compliance | cUL E27734, UL E27734 |
| Item | Humidity Controller |
| Width (In.) | 2-3/8 |
| Thermostat Switch Type | SPDT |
| For Use With | HE-67S3-0N0BT or HE-67S3-0N00P Series of Humidity Transmitters to Stage Humidification and Dehumidification Equipment |
| Application | Clean Rooms, Computer Rooms, Humidity Monitoring and Control, Pharmaceutical Manufacturing |
| Control Range | 10% to 90% |
| Overall Length | 5 in |
| Input Voltage | 120/240V AC |
| Standards | cUL Listed, UL Listed |
| Includes | HE-HE-67S3-0N0BT Room Sensor |
| Overall Depth | 3 in |
| Overall Width | 2-3/8 in |
| Overall Height | 5 in |
| Full Load Current | 1.8 A |
| Contact Form | SPDT |
| Series | W351 |
| Maximum Operating Temperature | 150 deg F |
| Dehumidifier Control Compatibility | Dehumidifier Control Compatible |
| Includes Outdoor Temperature Sensor | Outdoor Temperature Sensor Not Included |
| Humidifier Control Compatibility | Humidifier Control Compatible |
| Current Rating | 10 A |
| Product Type | Humidity Controller |
| Humidity Differential | 2% to 10% |
| Housing Material | Thermoplastic |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
