Line Volt Mechanical Tstat, Open/Close on Rise, 45 Degrees to 85 Degrees F, SPDT, 120 to 240V AC
| Switch Action | Open/Close on Rise |
|---|---|
| Voltage | 120 to 240V AC |
| Sensor Type | Hydraulic Capillary Bulb (Copper) |
| Differential | 4 Degrees F |
| Number of Relay Inputs | 1 |
| Thermostat Control Range | 45 to 85 deg F |
| Switch Type | SPDT |
| Color | Gray |
| Width | 3-1/2 in |
| Height | 4-1/4 in |
| Thermostat Switch Type | SPDT |
| Inductive Amps @ 240V | 8 A |
| Standards | CSA LR948/1222 01, UL SA516 |
| Full Load Amps @ 120VAC | 16 A |
| Mounting Type | Flat Surface |
| Capillary Length | 72 in |
| Pilot Duty Contacts (VA) | 125 VA |
| Locked Rotor Amps @ 240V | 48 A |
| Locked Rotor Amps @ 120V | 96 A |
| Inductive Amps @ 120V | 16 A |
| Control Range | 45 to 85 deg F |
| Thermostat Item | Line Voltage Mechanical Thermostat |
| Item | Line Volt Mechanical Tstat |
| Inductive Amps @ 208V | 9.2 A |
| Thermostat Heating/Cooling | Heating, Cooling |
| Sensing Bulb Length | 3-1/8 in |
| Contact Rating Resistive @ 277V | 22 A |
| Resistive Amps @ 208VAC | 22 A |
| Full Load Amps @ 240VAC | 8 A |
| Remote Sensing Capability | Yes |
| Depth | 2 in |
| Contact Rating Resistive @ 120V | 16 A |
| Includes | Remote Sensing Bulb |
| Contact Rating Resistive @ 240V | 8 A |
| Number of Switches | 1 |
| Enclosure Type | Galvanized/Steel |
| Remote Sensing Bulb Included | Yes |
| Sensing Bulb Dia. | 19/64 in |
| Thermostat Voltage | 24 to 277 V AC |
| Thermostat Programmable | No |
| Temp. Sensitivity | +/-4 deg F |
| Thermostat Type | Defrost Duration & Fan Delay Single-Stage Controls |
| For Use With | Defrost Duration and Fan Delay Control |
| Mounting | Flat Surface |
| Application | Heat and Cool |
| Number of Relay Outputs | 1 |
| Control Type | Exposed Dial |
| Fan Delay | Yes |
| Temperature Differential | 4 Degrees F |
| Compatible System Type | Refrigerator |
| Minimum Operating Temperature | -35 deg F |
| Sensor Location | Remote |
| Temperature Sensitivity | +/-4 deg F |
| Minimum Control Temperature | 85 deg F |
| Enclosure Material | Steel |
| Bulb Length | 3-1/8 in |
| Contact Rating | 120V AC, 208V AC, 240V AC, 277V AC |
| Full Load Amps @ 240V AC | 8 A |
| Differential Type | Fixed |
| Overall Height | 4-1/4 in |
| Defrost Termination | 45 to 85 deg F |
| Switch Type/Action | Open, Close, SPDT on Rise |
| Number of Poles | 1 |
| Bulb Diameter | 1/4 in |
| Changeover Type | Manual |
| Overall Depth | 2 in |
| Pilot Duty Rating | 125 VA @ 24 to 277V AC |
| Resistive Amps @ 208V AC | 9.2 A |
| Full Load Amps @ 120V AC | 16 A |
| Maximum Control Temperature | 85 deg F |
| Temperature Scale | Fahrenheit, Celsius |
| Enclosure NEMA Rating | 1 |
| Capillary Length/Bulb Diameter | 6 ft Capillary, 3 1/8 in x 5/16 in Bulb |
| Overall Width | 3-1/2 in |
| Enclosure Color | Gray |
| Temperature Control Range | 85 to 85 deg F |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
