Temperature Control, Open/Close on Rise, -35 to 55 F Degrees, SPDT, 24V AC
| Switch Action | Open/Close on Rise |
|---|---|
| Voltage | 24V AC |
| Sensor Type | Temperature |
| Differential | 0.5 Degrees to 17 Degrees F |
| Display Type | Analog |
| Number of Relay Inputs | 0 |
| Thermostat Control Range | -35 to 55 deg F |
| Switch Type | SPDT |
| Color | Gray |
| Width | 2-13/32 in |
| Height | 5 in |
| Includes | A99BC-25C Temperature Sensor |
| Thermostat Voltage | 24 to 277 V AC |
| Full Load Amps @ 240VAC | 4.9 A |
| Control Range | -35 to 55 F Degrees |
| Inductive Amps @ 208V | 4.9 A |
| Thermostat Heating/Cooling | Heating, Cooling |
| Remote Sensing Bulb Included | Yes |
| Inductive Amps @ 240V | 4.9 A |
| Inductive Amps @ 120V | 9.8 A |
| Depth | 2-13/32 in |
| Remote Sensing Capability | Yes |
| Standards | CCN XAPX, UL |
| Contact Rating Resistive @ 240V | 10 A |
| Pilot Duty Contacts (VA) | 125 VA |
| Thermostat Programmable | No |
| Contact Rating Resistive @ 277V | 10 A |
| Thermostat Item | Line Voltage Mechanical Thermostat |
| Locked Rotor Amps @ 120V | 58.8 A |
| Locked Rotor Amps @ 240V | 29.4 A |
| Resistive Amps @ 208VAC | 10 A |
| Contact Rating Resistive @ 120V | 10 A |
| Enclosure Type | NEMA 1 |
| Thermostat Switch Type | SPDT |
| Full Load Amps @ 120VAC | 15 A |
| Item | Temperature Control |
| Number of Switches | 1 |
| For Use With | Suitable for Temperature Control in Refrigeration Applications |
| Number of Relay Outputs | 0 |
| Overall Length | 5 in |
| Number of Stages | Single |
| Agency Compliance | UL, cUL |
| Thermostat Type | Mechanical |
| Application | Beverage Coolers, Chiller Control, Cooling Tower Control, Refrigeration, Temperature Sensing and Control |
| Input Voltage | 120V AC, 240V AC |
| Dual Transformer Compatible | No |
| Dehumidification Control | No |
| Humidification Control | No |
| Features | Field Selectable Heat/Cool Mode, Adjustable Set Point and Differential, LED Indication of Relay Status, (5) Pin Connectors |
| Control Type | Exposed Dial |
| Type | Heating/Cooling |
| Voltage Range | 24 to 277 VAC |
| Temperature Scale | Fahrenheit |
| Mounting Direction | Vertical |
| Temperature Readout | No |
| Digit Size | Standard |
| Mounting Direction/Shape | Vertical |
| Electrical Connection Type | 5-Pin Connector |
| Housing Material | Silicon |
| Compatible System Type | Electric Forced Air Furnaces |
| Overall Depth | 2-3/8 in |
| Overall Height | 5 in |
| Maximum Control Temperature | 130 deg F |
| Differential Type | Adjustable |
| Minimum Control Temperature | -30 deg F |
| Overall Width | 2-3/8 in |
| Operating Humidity Range | 0 to 95% |
| Operating Temperature Range | 30 to 150 deg F |
| Housing Color | Gray |
| Pilot Duty Rating | 125 VA |
| Shape | Rectangle |
| Frequency | 50 Hz, 60 Hz |
| Sensor Location | Remote |
| Number of Sensor Inputs | 1 |
| Variable Output Voltage | No |
| Horsepower @ 240V AC | 0.5 HP |
| Horsepower @ 120V AC | 0.5 HP |
| Resistive Load Current @ 120V | 58.8 A |
| Number of Sensors Included | 1 |
| Temperature Control Function | Cool, Heat |
| Full Load Current @ 120V AC | 9.8 A |
| NEMA Rating | 1 |
| Contact Form | SPDT |
| Maximum Temperature Differential Setting | 30 deg F |
| IP Rating | IP20 |
| Minimum Temperature Differential Setting | 1 Degrees F |
| Resistive Load Current @ 240V | 29.4 A |
| Ambient Humidity | 0% to 95% RH |
| Full Load Current @ 240V AC | 4.9 A |
| Product Type | Temperature Control |
| Number of SPDT Outputs | 1 |
| Compatible with Series | 350 |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
