Takes 10 Inserts, 0/90° Lead Angle, 63mm High, MDHX 1004.. Insert Style, Series Fix-Perfect
| Maximum Cutting Diameter (Decimal Inch) | 4.9213 |
|---|---|
| Maximum Cutting Diameter (mm) | 125.00 |
| Maximum Depth of Cut (mm) | 1.00 |
| Arbor Hole Diameter (mm) | 40.00 |
| Arbor Hole Diameter (Decimal Inch) | 1.5748 |
| Compatible Insert Size Code | MDHX 1004.. |
| Cutter Style | CF |
| Insert Holding Method | Screw; Clamp |
| Lead Angle | 0/90 |
| Series | Fix-Perfect |
| Overall Height (Decimal Inch) | 2.4803 |
| Hub Diameter (mm) | 104.00 |
| Complete Insert Compatibility | MDHX 1004ZDFRGD4W |
| UNSPSC Code | 27112803 |
| Number Of Cutter Inserts | 10 |
| Number Of Flutes | 10 |
| Country of Origin | Czechia |
| MSC Number | MSC# 46862942 |
