Takes 4 Inserts, 0/90° Lead Angle, 40mm High, 4.21103.. Insert Style, Series Fix-Perfect
| Maximum Cutting Diameter (Decimal Inch) | 1.9685 |
|---|---|
| Maximum Cutting Diameter (mm) | 50.00 |
| Maximum Depth of Cut (mm) | 10.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.3937 |
| Arbor Hole Diameter (mm) | 16.00 |
| Arbor Hole Diameter (Decimal Inch) | 0.6299 |
| Compatible Insert Size Code | 4.21103.. |
| Cutter Style | P8 |
| Insert Holding Method | Screw; Clamp |
| Lead Angle | 0/90 |
| Series | Fix-Perfect |
| Maximum Body Diameter (Decimal Inch) | 1.8976 |
| Overall Height (Decimal Inch) | 1.5748 |
| Hub Diameter (mm) | 33.00 |
| Hub Diameter (Decimal Inch) | 1.2992 |
| Complete Insert Compatibility | 4.21103R6 |
| UNSPSC Code | 27112803 |
| Number Of Cutter Inserts | 4 |
| Number Of Flutes | 4 |
| Country of Origin | Czechia |
| undefined | undefined |
| MSC Number | MSC# 46863338 |
