Takes 6 Inserts, HNGJ 0905 Insert, Right Hand Cut, 6 Flutes, Through Coolant, Series Mill 1-18
| Minimum Cutting Diameter (mm) | 63.00 |
|---|---|
| Maximum Cutting Diameter (mm) | 74.00 |
| Maximum Depth of Cut (mm) | 4.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.1772 |
| Arbor Hole Diameter (mm) | 22.00 |
| Arbor Hole Diameter (Decimal Inch) | 0.8661 |
| Compatible Insert Size Code | HNGJ 0905 |
| Cutter Style | KSHR |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Series | Dodeka Series |
| Hub Diameter (mm) | 50.00 |
| Hub Diameter (Decimal Inch) | 1.9685 |
| Overall Height (Decimal Inch) | 1.5748 |
| Pitch Type | Coarse |
| Maximum RPM | 10100 |
| Complete Insert Compatibility | HNGJ 0905ANENLD; HNGJ 0905ANSNGD |
| Number Of Cutter Inserts | 6 |
| Coolant Through | Yes |
| Number Of Flutes | 6 |
| UNSPSC Code | 23291600 |
| Country of Origin | Spain |
| undefined | undefined |
| MSC Number | MSC# 77461861 |
