20 x 20 mm Shank, Uses EG0300M03P02 Inserts, Series Beyond Evolution
| Hand of Holder | Left Hand |
|---|---|
| Maximum Depth of Cut (Decimal Inch) | 0.6300 |
| Maximum Depth of Cut (mm) | 16.00 |
| Maximum Workpiece Diameter (mm) | 32.00 |
| Maximum Workpiece Diameter (Decimal Inch) | 1.2600 |
| Toolholder Style | EVSM |
| Compatible Insert Size Code | EG0300M03P02 |
| Overall Length (Decimal Inch) | 4.9210 |
| Overall Length (mm) | 125.00 |
| Insert Holding Method | Clamp |
| Shank Width/Diameter (Decimal Inch) | 0.7870 |
| Shank Width/Diameter (mm) | 20.00 |
| Shank Height (Decimal Inch) | 0.7870 |
| Shank Height (mm) | 20.00 |
| Shank Length (mm) | 88.00 |
| Shank Length (Decimal Inch) | 3.4640 |
| Series | Beyond Evolution |
| Head Height (mm) | 28.50 |
| Head Height (Decimal Inch) | 1.1220 |
| Head Length (Decimal Inch) | 1.4570 |
| Head Length (mm) | 37.00 |
| Insert Seat Size | 3 |
| Maximum Insert Width (Decimal Inch) | 0.0960 |
| Maximum Insert Width (mm) | 2.45 |
| UNSPSC Code | 23153308 |
| Blade Width (mm) | 2.45 |
| Blade Width (Decimal Inch) | 0.0960 |
| Complete Insert Compatibility | EG0300M03P02 |
| Coating Classification | Kennametal |
| Coolant Through | Yes |
| Country of Origin | India |
| undefined | undefined |
| MSC Number | MSC# 54320072 |
