Series KSEM Plus
| Head Connection Size | FDS28 |
|---|---|
| Drill Depth by Diameter Ratio | 10xD |
| Shank Type | Whistle Notch |
| Shank Diameter (mm) | 32.00 |
| Shank Diameter (Decimal Inch) | 1.2598 |
| Toolholder Style | WD |
| Nose Diameter (Decimal Inch - 4 Decimals) | 1.0433 |
| Nose Diameter (Mm) ( - 2 Decimals) | 26.50 |
| Overall Length (Decimal Inch) | 15.8660 |
| Overall Length (mm) | 403.00 |
| Through Coolant | Yes |
| Series | KSEM Plus |
| Flute Length (mm) | 288.00 |
| Flute Length (Decimal Inch) | 11.3386 |
| Shank Length (mm) | 58.00 |
| Shank Length (Decimal Inch) | 2.2835 |
| Gage Length (mm) | 345.00 |
| Gage Length (Decimal Inch) | 13.5827 |
| Coolant Hole Thread Type | NPT |
| Coolant Through | Yes |
| UNSPSC Code | 23153308 |
| Country of Origin | Germany |
| MSC Number | MSC# 46891172 |
