Screw, Uses 10 Inserts, LNE 1245 Inserts, 5 Tooth, Staggered Teeth
| Cutting Width (mm) | 8.00 |
|---|---|
| Maximum Depth of Cut (Decimal Inch) | 0.8661 |
| Maximum Depth of Cut (mm) | 22.00 |
| Hole Diameter (Mm) ( - 0 Decimals) | 27.00 |
| Hole Diameter (Decimal Inch) | 1.6300 |
| Cutter Diameter (Decimal Inch) | 3.9370 |
| Cutter Diameter (Inch) | 3-15/16 |
| Cutter Diameter (mm) | 100.00 |
| Shank Diameter (Inch) | 1-1/16 |
| Shank Diameter (Decimal Inch) | 1.0630 |
| Insert Holding Method | Screw |
| Number Of Cutter Inserts | 10 |
| Compatible Insert Style | LNE 1245 |
| Tooth Type | Staggered |
| Series | LN |
| Toolholder Style | 90° LN |
| Hub Diameter (Decimal Inch) | 1.9685 |
| Hub Diameter (mm) | 50.00 |
| Primary Workpiece Material | Stainless Steel; Cast Iron; Superalloys & Titanium; Steel |
| Primary Workpiece Material Code | P; S; K; M |
| Minimum Cutting Width (Decimal Inch) | 0.3150 |
| Maximum Cutting Width (Decimal Inch) | 0.3543 |
| Maximum Cutting Width (mm) | 9.00 |
| UNSPSC Code | 23241629 |
| Manufacturers Catalog Number | 100Y10RS90LN12N08 |
| Number Of Teeth | 5 |
| Country of Origin | Germany |
| undefined | undefined |
| MSC Number | MSC# 46866612 |
