Uses (2) LNGU15T608SRGE Inserts, 1 mm OAL
| Cutting Diameter | 0.9840 in |
|---|---|
| Cutting Diameter (mm) | 25.00 |
| Overall Length (Decimal Inch) | 3.9370 |
| Overall Length (mm) | 1.00 |
| Maximum Depth of Cut (mm) | 15.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.6100 |
| Cutter Style | M4D025Z02A25LN15L100 |
| Shank Type | Cylindrical |
| Shank Diameter (Decimal Inch) | 0.9840 |
| Shank Diameter (mm) | 25.00 |
| Insert Holding Method | Screw |
| Series | MILL 4-15 |
| Lead Angle | 0 |
| Insert Compatibility | LNGU15T608SRGE |
| UNSPSC Code | 27112803 |
| ISO Number | M4D025Z02A25LN15L100 |
| Number Of Cutter Inserts | 2 |
| Country of Origin | VARIOUS |
| MSC Number | MSC# 44657153 |
