Series Top Notch
| Thread Type | Internal; External |
|---|---|
| Hand of Holder | Right Hand |
| Shank Width/Diameter (Decimal Inch) | 1.2500 |
| Shank Width/Diameter (mm) | 31.75 |
| Shank Width/Diameter (Inch) | 1-1/4 |
| Toolholder Style | NS |
| Insert Compatibility | N.5R |
| Insert Holding Method | Clamp |
| Shank Height (mm) | 31.75 |
| Shank Height (Decimal Inch) | 1.2500 |
| Shank Height (Inch) | 1-1/4 |
| Overall Length (mm) | 152.40 |
| Overall Length (Inch) | 6 |
| Overall Length (Decimal Inch) | 6.0000 |
| Multi-use Tool | No |
| Head Length (Decimal Inch) | 2.0000 |
| Head Length (mm) | 50.80 |
| Maximum Depth of Cut (Decimal Inch) | 0.4150 |
| Maximum Depth of Cut (mm) | 10.54 |
| Back of Bar to Cutting Edge (Decimal Inch) | 1.5000 |
| UNSPSC Code | 23291800 |
| Coolant Through | No |
| Series | Top Notch |
| Country of Origin | Bulgaria |
| MSC Number | MSC# 88229406 |
