NC Spotting Drills, 118 deg., 3/16in., TiN
| Item | Spotting Drill Bit |
|---|---|
| Material - Machining | High Speed Steel |
| Drill Bit Point Angle | 118 Degrees |
| Size - Decimal | 1/8 in - 0.1250 |
| Measurement System | Fractional Inch |
| Finish - Machining | TiN |
| Flute Length | 1/2 in |
| Overall Length | 1-3/8 in |
| Shank Dia. | 3/16 in |
| Drill Bit Finish | TiN |
| Material | High Speed Steel |
| Drill Bit Size | 3/16 in |
| Drill Bit Grouping | Drill Bit |
| Finish | Tin |
| Application | Can Be Chucked Close to The Point, Ensuring Accuracy and True Starts |
| Drill Size | 3/16 in |
| Left/Right Hand | Right Hand |
| Decimal Equivalent | 0.1875 |
| Drill Point (Deg.) | 118 |
| Body Dia. | 3/16 in |
| Drill Bit Material | High Speed Steel |
| Number of Pieces | 1 |
| Cutting Direction - Machining | Right Hand |
| Drill Bit Dimension Type | Fractional Inch |
| Sizes Included | 3/16" |
| Size (In.) | 3/16 |
| Package Quantity | 1 |
