Aluminum Electrical Enclosures, 8 in H, 6 in D, 8 in W, NEMA 4, Bolted
| Item | Electrical Enclosures |
|---|---|
| Nominal Width | 8 in |
| Nominal Height | 8 in |
| Nominal Depth | 6 in |
| Enclosure NEMA Rating | NEMA 4 |
| Material of Enclosure | Aluminum |
| Closure Method | Bolted |
| Enclosure Cover Type | Bolted |
| Metallic / Non-Metallic | Metallic |
| Color | Silver |
| Finish | Powder Epoxy/Polyester |
| Solid / Clear Cover | Solid |
| Series | EXB |
| NEMA Rating | 3, 4, 4X, 7 (B,C,D), 9 (E,F,G) |
| Safety Rating | Class 1, Division 1 |
| Lid Hinge | Yes |
| Mounting Type | Wall Mount |
| Material | Aluminum |
| Max. Conduit Size | 2 in |
| Standards | CSA File No. LR11716, IEC E x 07.0022U/IEC E x 07.0023, PTB 07 ATEX 1025U/PTB 07 ATEX 1024, UL File No. E10514/E83696/E12379 |
| Interior Panel | 2NWE2 |
| Usable Opening Depth | 6.06 in |
| Enclosure Material | Copper-Free Aluminum |
| Gasket | Nitrile |
| CSA File Number | LR11716 |
| Application | Locations made hazardous due to the presence of flammable gases or vapors, combustible dust, or easily ignitable fibers and flyings, and areas which are subject to corrosion, weather, and dampness. Petroleum refineries, chemical and petrochemical plants w |
| Hazardous Location Specification | Class I, Div 1 and 2, Group B, C, D, Class II, Div 1 and 2, Group E, F, G, Class III, Div 1 and 2 |
| Gasket Material | Nitrile |
| Environment - MERCH | Washdown and Corrosion Resistant |
| Cover Style | Solid |
| NEMA Enclosure Rating | 4, 4X, 3 |
| Cover Closure Type | Bolt On |
| Package Quantity | 1 |
