Cable Clamp, 3/16" dia., 1/2" W, PK1000
| Item | Cable Clamp |
|---|---|
| Clamp Material | Galvanized Steel |
| Clamp Finish | Hot Dipped Galvanized |
| Coating Material | Galvanized |
| Liner Color | Black |
| Clamp Thickness | 0.032 in |
| Clamp Band Width | 1/2 in |
| Cable Clamping Dia. | 3/16 in |
| Cushion Type | Extruded EPDM |
| Mounting Hole Dia. | 0.2813 in |
| Temp. Range (F) | -50 to 350 |
| Type | Cushioned |
| Package Quantity | 1000 |
| Clamp Color | Gray |
| Standards | ASTM A240/A666, ASTM A653/A653M, ASTM B209 |
| Material | Steel |
| Thickness | 0.032 in |
| Finish | Galvanized |
| Additional Features | Part# COL0309Z1 3/16 In. Diameter Medium Duty Clamp Hot-Dipped Galvanized Steel, Chem-Treated G90 Black EPDM Rubber Cushion Manufactured by KMC Stampings 0.187 In. Clamping Diameter 0.281 In. Screw Hole Size 0.5 In. Width 0.032 In. Material Thickness |
| Mounting Hole Diameter | 9/32 in |
| Operating Temperature - Maximum | 350 deg F |
| Product Type | Clamp |
| Band Width | 1/2 in |
| Clamping Diameter - Maximum | 3/16 in |
| Operating Temperature - Minimum | -50 deg F |
| Cushion Material | EPDM Rubber |
