16x16x2 Pleated Air Filter, High Capacity, Synthetic, MERV 13
| Performance Rating | MERV 13 |
|---|---|
| Air Filter Capacity | High Capacity |
| Air Flow @ 300 fpm | 900 cfm |
| Media Material | Synthetic |
| Nominal Filter Size | 16x16x2 |
| Frame or Header Material | Beverage Board Reinforced with Expanded Metal |
| Item | Pleated Air Filter |
| Nominal Depth | 2 in |
| Nominal Height | 16 in |
| Nominal Width | 16 in |
| Actual Height | 15-1/2 in |
| Max. Temp. | 200 deg F |
| Max. Velocity | 500 fpm |
| Standards | ASHRAE Test Standard 52.2-2012 |
| Actual Depth | 1-3/4 in |
| Final Recommended Resistance | 1 in wc |
| Media Area | 7 sq ft |
| Actual Width | 15-1/2 in |
| Media Color | Green |
| Style - Air Filters | Pleated |
| Air Flow @ 500 fpm | 900 cfm |
| Common Applications | General Use |
| Pleats per Linear Foot | 15 |
| Initial Resistance @ 500 fpm | 0.29 in wc |
| Air Flow @ 625 fpm | 1,125 cfm |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
