| Head Connection Size | 0.7480 in |
|---|---|
| Maximum Drill Diameter (Decimal Inch) | 1.0000 |
| Pilot Drill Diameter (Decimal Inch) | 0.1969 |
| Pilot Drill Style | V95 |
| Drill Head Style | V46 |
| Insert Holding Method | Screw |
| Head Length (Decimal Inch) | 0.91 |
| Series | V46 |
| Back of Head Diameter (Decimal Inch) | 0.7480 |
| Overall Length (Decimal Inch) | 1.4402 |
| Head Length to Pilot Tip (Decimal Inch) | 0.0035 |
| Coolant Through | Yes |
| Number of Non Pilot Inserts | 2 |
| UNSPSC Code | 23291500 |
| Country of Origin | Germany |
| undefined | undefined |
| MSC Number | MSC# 13103155 |
