16" Bend Radius, 22 InHg & 24 InHg Vacuum Rating, 30 psi, CXE Camlock
| Connection Type | CXE Camlock |
|---|---|
| Minimum Working Temperature (Deg F) | -4 |
| Maximum Working Temperature (F) | 150.000 |
| Maximum Working Pressure (PSI - 3 Decimals) | 30.000 |
| Bend Radius (Inch) | 16 |
| Vacuum Rating | 22 InHg; 24 InHg |
| Color | Clear |
| Additional Information | Working Pressure: 30 psi at 68 degree F, 15 psi at 104 degree F; Vacuum Rating: 24 InHg at 68 degree F, 22 InHg at 104 degree F |
| Inside Diameter (Inch) | 5 |
| Overall Length (Feet) | 1 |
| Outside Diameter (Decimal Inch) | 5.7400 |
| UNSPSC Code | 40142012 |
| Country of Origin | UNITED STATES |
| undefined | undefined |
| MSC Number | MSC# 14751283 |
