Milling Insert, Pentagon, PNMG 1106XNENGH PR1510 Grade PVD Carbide
| Item | Parallelogram Milling Insert |
|---|---|
| Insert Style | PNMG |
| Insert Size | 1,106 |
| Chip-Breaker | Yes |
| ISO Number | PNMG1106XNEN-GH |
| Rake | Positive |
| Cutting Direction | Neutral |
| Thickness | 6.35 mm |
| Features | 2.00mm Wiper Edge Length, For Gray and Nodular Cast Iron, Wear Resistance and High Oxidation Resistance |
| Finish - Machining | Megacoat Nano |
| Insert Holding Type | Screw Held |
| Coating Process | PVD |
| Cutting Application | Chamfering, Facing |
| Number of Cutting Edges | 10 |
| Measurement System | Metric |
| Cutting Edge Length | 17.23 mm |
| ANSI Code | PNMG1106XNENGH |
| Material - Machining | Carbide |
| Manufacturer Grade | PR1510 |
| Wiper Insert | Yes |
| Primary Material Application ISO Code | K |
| Cutting Edge | Honed, Tough Edge |
| Primary Material Application | Cast Iron |
| Chip-Breaker Code | XNEN-GH |
| For Toolholder | MFK...-11 |
| Shape | Pentagon |
| Hole Type | Screw Hole |
| Package Quantity | 1 |
