Milling Insert, Round, RPMW 1204M0TN PR1525 Grade PVD Carbide
| Item | Parallelogram Milling Insert |
|---|---|
| Insert Style | RPMW |
| Insert Size | 1,204 |
| Cutting Direction | Neutral |
| ISO Number | RPMW1204M0TN |
| Rake | Positive |
| Mounting Hole Dia. | 4.4 mm |
| Chip-Breaker | Yes |
| Inscribed Circle | 12 mm |
| Thickness | 4.76 mm |
| Features | For Carbon/Alloy, Free-Cutting and Mold Steel, Wear Resistance and High Oxidation Resistance |
| For Toolholder | MRX...-12 |
| Primary Material Application ISO Code | P |
| Hole Type | Countersunk Hole |
| Secondary Material Application | Austenitic Stainless Steel |
| Coating Process | PVD |
| Measurement System | Metric |
| Cutting Application | Facing, Grooving, Plunging, Pocketing, Radius Milling, Shouldering |
| Clearance Angle | 11 deg |
| Insert Holding Type | Screw Held |
| ANSI Code | RPMW1204M0TN |
| Finish - Machining | Megacoat Nano |
| Material - Machining | Carbide |
| Secondary Material Application ISO Code | M |
| Primary Material Application | Steel |
| Through Hole Inside Dia. | 4.4 mm |
| Cutting Edge | Double Chamfered, Flat Top |
| Chip-Breaker Code | TN |
| Shape | Round |
| Manufacturer Grade | PR1525 |
| Package Quantity | 1 |
