Milling Insert, Square, SEKW 421FN KW10 Grade Uncoated Carbide
| Item | Parallelogram Milling Insert |
|---|---|
| Insert Style | SEKW |
| Insert Size | 421 |
| Corner Radius | 1/64 in |
| ISO Number | SEKW120304FN |
| Chip-Breaker | Yes |
| Mounting Hole Dia. | 0.2165 in |
| Inscribed Circle | 1/2 in |
| Cutting Direction | Neutral |
| Rake | Positive |
| Width | 1/2 in |
| Thickness | 1/8 in |
| Clearance Angle | 20 deg |
| Cutting Application | Back Chamfering, Chamfering, Countersinking, V-Shape Slotting |
| Primary Material Application | Aluminum, Brass, Bronze, Copper, Non-Ferrous |
| ANSI Code | SEKW421FN |
| Chip-Breaker Code | FN |
| Number of Cutting Edges | 4 |
| Manufacturer Grade | KW10 |
| Measurement System | Fractional Inch |
| Primary Material Application ISO Code | N |
| Insert Holding Type | Screw Held |
| Through Hole Inside Dia. | 0.2165 in |
| Included Angle | 90 deg |
| Finish - Machining | Bright |
| For Toolholder | MCSE106, MCSE108-30D, MCSE108-60D, MCSE110-30D, MCSE115, MCSE120-60D, MCSE227, MCSE336 |
| Material - Machining | Carbide |
| Shape | Square |
| Cutting Edge | Sharp Edge |
| Secondary Material Application ISO Code | K |
| Hole Type | Countersunk Hole |
| Secondary Material Application | Cast Iron |
| Package Quantity | 1 |
