Milling Insert, Square, SPMT 090304EZ KW10 Grade Uncoated Carbide
| Item | Parallelogram Milling Insert |
|---|---|
| Insert Style | SPMT |
| Insert Size | 90,304 |
| Corner Radius | 1/64 in |
| Inscribed Circle | 3/8 in |
| Mounting Hole Dia. | 0.1339 in |
| ISO Number | SPMT090304E-Z |
| Rake | Positive |
| Chip-Breaker | Yes |
| Cutting Direction | Neutral |
| Width | 3/8 in |
| Thickness | 1/8 in |
| Material - Machining | Carbide |
| Insert Holding Type | Screw Held |
| Manufacturer Grade | KW10 |
| Hole Type | Countersunk Hole |
| For Toolholder | MEF...-S25, MEF...-S32 |
| Secondary Material Application | Cast Iron |
| Finish - Machining | Bright |
| Primary Material Application ISO Code | N |
| Number of Cutting Edges | 4 |
| Through Hole Inside Dia. | 0.1339 in |
| Secondary Material Application ISO Code | K |
| Chip-Breaker Code | E-Z |
| Measurement System | Fractional Inch |
| Cutting Application | Bolt Counterboring, Facing, Shouldering |
| Shape | Square |
| Primary Material Application | Aluminum, Brass, Bronze, Copper, Non-Ferrous |
| Included Angle | 90 deg |
| Clearance Angle | 11 deg |
| ANSI Code | SPMT090304EZ |
| Package Quantity | 1 |
