Milling Insert, Triangle, TEEN 43PTTR TN100M Grade Uncoated Cermet
| Item | Parallelogram Milling Insert |
|---|---|
| Insert Style | TEEN |
| Insert Size | 43 |
| Rake | Positive |
| Cutting Direction | Right Hand |
| Inscribed Circle | 1/2 in |
| Chip-Breaker | Yes |
| ISO Number | TEEN2204PTTR |
| Features | For Carbon/Alloy, Free-Cutting and Mold Steel, Tough Cermet with Improved Oxidation Resistance and Thermal Shock Resistance |
| Thickness | 3/16 in |
| For Toolholder | MTE9050, MTE9063, MTE9080-32 |
| Primary Material Application ISO Code | P |
| Insert Holding Type | Clamp |
| Included Angle | 60 deg |
| Measurement System | Fractional Inch |
| Wiper Insert | Yes |
| ANSI Code | TEEN43PTTR |
| Cutting Edge | Chamfered |
| Cutting Application | Facing, Shouldering, Slotting |
| Number of Cutting Edges | 3 |
| Hole Type | No Hole |
| Chip-Breaker Code | PTTR |
| Finish - Machining | Bright |
| Primary Material Application | Steel |
| Shape | Triangle |
| Clearance Angle | 20 deg |
| Material - Machining | Cermet |
| Feed Type | High |
| Manufacturer Grade | TN100M |
| Package Quantity | 1 |
