Milling Insert, Triangle, TEKN 43PTTR PR1225 Grade PVD Carbide
| Item | Parallelogram Milling Insert |
|---|---|
| Insert Style | TEKN |
| Insert Size | 43 |
| Inscribed Circle | 1/2 in |
| ISO Number | TEKN2204PTTR |
| Cutting Direction | Right Hand |
| Rake | Positive |
| Chip-Breaker | Yes |
| Features | For Carbon/Alloy, For Light interrupted to Interrupted Cutting of Stainless Steel, Free-Cutting and Mold Steel, Superior Wear and Oxidation Resistance |
| Thickness | 3/16 in |
| Primary Material Application | Stainless Steel, Steel |
| Included Angle | 60 deg |
| Shape | Triangle |
| Coating Process | PVD |
| Hole Type | No Hole |
| Cutting Application | Facing, Shouldering, Slotting |
| Material - Machining | Carbide |
| Finish - Machining | Megacoat |
| Insert Holding Type | Clamp |
| Chip-Breaker Code | PTTR |
| Primary Material Application ISO Code | P, M |
| For Toolholder | MTE9050, MTE9063, MTE9080-32 |
| Number of Cutting Edges | 3 |
| ANSI Code | TEKN43PTTR |
| Measurement System | Fractional Inch |
| Cutting Edge | Chamfered |
| Clearance Angle | 20 deg |
| Wiper Insert | Yes |
| Manufacturer Grade | PR1225 |
| Package Quantity | 1 |
