Milling Insert, Trigon, WNMU 080608ENGH CA6535 Grade CVD Carbide
| Item | Parallelogram Milling Insert |
|---|---|
| Insert Style | WNMU |
| Insert Size | 80,608 |
| Corner Radius | 0.8 mm |
| Chip-Breaker | Yes |
| Cutting Direction | Neutral |
| Mounting Hole Dia. | 6.2 mm |
| Rake | Positive |
| ISO Number | WNMU080608EN-GH |
| Inscribed Circle | 14.02 mm |
| Thickness | 6.65 mm |
| Features | 1.30mm Wiper Edge Length, For Ni-Based Heat-Resistant Alloys and Martensitic Stainless Steel, High Heat and Wear Resistance |
| Cutting Application | Facing, Shouldering, Slotting |
| Wiper Insert | Yes |
| Coating Process | CVD |
| Material - Machining | Carbide |
| Number of Cutting Edges | 6 |
| Primary Material Application ISO Code | S |
| Secondary Material Application ISO Code | M |
| Cutting Edge | Honed, Tough Edge |
| Chip-Breaker Code | EN-GH |
| Shape | Trigon |
| Through Hole Inside Dia. | 6.2 mm |
| Secondary Material Application | Martensitic Stainless Steel |
| Insert Holding Type | Screw Held |
| Measurement System | Metric |
| ANSI Code | WNMU080608ENGHC35 |
| Manufacturer Grade | CA6535 |
| Finish - Machining | TiCN+Al2O3+TiN |
| Included Angle | 80 deg |
| Hole Type | Screw Hole |
| For Toolholder | MFWN90... |
| Primary Material Application | High-Temperature Alloys |
| Package Quantity | 1 |
