Butt Hinge, Bronze, Full Surface Mounting, 2 9/16 in Leaf W x 3 15/16 in Leaf H, Anodized
| Corners | Square |
|---|---|
| Door Leaf Height | 3-15/16 in |
| Door Leaf Thickness | 0.138 in |
| Door Leaf Width | 2-3/8 in |
| Finish | Anodized |
| Holes per Leaf | 3 |
| Load Capacity | 28.6 lb |
| Material | Bronze |
| Mounting | Full Surface |
| Orientation | Non Handed |
| Pin Dia. | 35/64 in |
| Range of Motion | 180 deg |
| Features | Caps |
| Frame Leaf Height | 3-15/16 in |
| Bearing Type | Pin |
| Frame Leaf Width | 2-9/16 in |
| Overall Knuckle Height | 5 in |
| Holes | With |
| Item | Butt Hinge |
| Hinge Number | Not Applicable |
| Frame Leaf Thickness | 0.138 in |
| Pin Type | Removable |
| Ligature Resistant | No |
| Hardware | Yes |
| Pin Material | 304 Stainless Steel |
| Overall Width | 2-9/16 in |
| Standards | RoHS Compliant |
| Hand Orientation | Non-Handed |
| Includes Hardware | Hardware Included |
| Range of Motion - Maximum | 180 deg |
| Number of Holes per Leaf | 3 |
| Removable Pin | Yes |
| Mounting Style | Full Surface |
| Pin Diameter | 9/16 in |
| ANSI/BHMA Finish | Clear Anodized, Satin Aluminum |
| Door Thickness - Minimum | Not Applicable |
| Corner Type | Square |
| Resistance Properties | Corrosion-Resistant |
| Country of Origin (subject to change) | Japan |
| Package Quantity | 1 |
