Door and Butt Hinge, 304 Stainless Steel, Weld-On Mounting, 3 11/16 in Leaf W x 3 1/8 in Leaf H
| Corners | Square |
|---|---|
| Door Leaf Height | 3-1/8 in |
| Door Leaf Thickness | 0.313 in |
| Door Leaf Width | 3-11/16 in |
| Finish | Satin |
| Holes per Leaf | 4, 1 |
| Load Capacity | 5.7 lb |
| Material | 304 Stainless Steel |
| Mounting | Weld-On |
| Orientation | Non Handed |
| Pin Dia. | 19/64 in |
| Range of Motion | 180 deg |
| Features | 17-3/4" Door Width; 27-9/16" Door Height |
| Item | Door and Butt Hinge |
| Frame Leaf Height | 3-1/8 in |
| Frame Leaf Width | 3-11/16 in |
| Holes | With |
| Ligature Resistant | No |
| Frame Leaf Thickness | 0.313 in |
| Bearing Type | Plain |
| Pin Type | Non-Removable |
| Pin Material | Stainless Steel |
| Hardware | Yes |
| Standards | RoHS Compliant |
| Overall Width | 3-11/16 in |
| Hinge Number | Not Applicable |
| Overall Knuckle Height | 18 in |
| Hand Orientation | Non-Handed |
| ANSI/BHMA Finish | Satin Stainless Steel |
| Pin Diameter | 5/16 in |
| Corner Type | Square |
| Range of Motion - Maximum | 180 deg |
| Resistance Properties | Corrosion-Resistant |
| Mounting Style | Full Surface |
| Number of Holes per Leaf | 5 |
| Door Thickness - Minimum | Not Applicable |
| Includes Hardware | Hardware Included |
| Removable Pin | No |
| Country of Origin (subject to change) | Japan |
| Package Quantity | 1 |
