Lift-Off Hinge, Bronze, Full Surface Mounting, 29/32 in Leaf W x 2 9/16 in Leaf H, Anodized
| Corners | Square |
|---|---|
| Door Leaf Height | 2-9/16 in |
| Door Leaf Thickness | 0.138 in |
| Door Leaf Width | 29/32 in |
| Finish | Anodized |
| Holes per Leaf | 2 |
| Load Capacity | 17.5 lb |
| Material | Bronze |
| Mounting | Full Surface |
| Orientation | Non Handed |
| Pin Dia. | 35/64 in |
| Range of Motion | 180 deg |
| Features | No Metal to Metal Contact; Ideal for Clean Room Application |
| Frame Leaf Height | 2-9/16 in |
| Frame Leaf Thickness | 0.138 in |
| Pin Material | Stainless Steel |
| Hardware | Yes |
| Holes | With |
| Frame Leaf Width | 29/32 in |
| Item | Lift-Off Hinge |
| Pin Type | Nonremovable |
| Ligature Resistant | No |
| Overall Width | 60 mm |
| Range of Motion - Maximum | 180 deg |
| Mounting Style | Full Surface |
| Number of Holes per Leaf | 4 |
| Pin Diameter | 35/64 in |
| Includes Holes | Holes Included |
| Includes Hardware | Hardware Included |
| ANSI/BHMA Finish | Clear Anodized, Satin Aluminum |
| Corner Type | Square |
| Country of Origin (subject to change) | Japan |
| Package Quantity | 1 |
