Este receptáculo angular de color rojo con nariz cónica y conexión macho es ideal para una variedad de aplicaciones eléctricas. Fabricado por la reconocida marca Leviton, garantiza calidad y durabilidad.
| Item | Angled Receptacle |
|---|---|
| Type | Cam-Type |
| Series | 16 |
| Terminal Connection | Double Set Screw |
| Male/Female | Male |
| Current Rating | 400 A |
| Voltage Rating | 600VAC/250VDC |
| NEMA Rating | 3R, 4X, 12 |
| Standards | UL & CSA |
| Material | Thermoplastic Elastomer |
| Color | Red |
| Conductor Material | Solid Brass |
| Single Pole Device Style | Taper Nose |
| Mounting | Screw Mount |
| Cable Range | 2/0 to 4/0 |
| Fits | Female Plug |
| Amps AC/DC | 300/400AC/DC |
| Length | 8 in |
| Width | 11 in |
| Height | 7-1/4 in |
| Application | Sports, Entertainment and Movie Industry, Welding and Construction Sites, Theme Parks and Carni |
| Standard | UL: 1691 |
| Package Quantity | 1 |
