Circuit Breaker Enclosure, LP, 8 Spaces, 150A, Main Circuit Breaker
| Item | Circuit Breaker Enclosure |
|---|---|
| Main Circuit Breaker or Main Lug | Main Circuit Breaker |
| Number of Spaces | 8 |
| Amps | 150A |
| Short Circuit Current Rating | 22kA |
| Height | 18-1/2 in |
| Width | 16.6 in |
| Depth | 5.2 in |
| Series | LP |
| Enclosure NEMA Rating | NEMA 3R |
| Bus Material | Copper |
| Color | Gray |
| Mounting Style | Wall Mount |
| Application | LOAD CENTERS |
| Temperature Rating | -40?C to 85?C |
| Standard | UL 869A, UL 50, UL 67, UL 50E |
| Package Quantity | 1 |
