Este interruptor de circuito de alta calidad de Leviton está diseñado para manejar corriente de hasta 30 amperios a 250 voltios de corriente continua o 600 voltios de corriente alterna. Cuenta con 2 o 3 polos para una mayor versatilidad en la instalación.
| Item | Circuit Interruptor |
|---|---|
| Number of Poles | 2, 3 |
| Voltage Rating | 600 VAC, 250 VDC |
| Color | Black |
| Length | 17-3/4 in |
| Voltage | 250VDC/600V AC |
| Body Material | Nylon |
| Amps | 30/20A |
| Height | 9-1/8 in |
| Amperage | 30/20 A |
| Wire | 4 |
| Environment | Dry |
| Assembly Screws | Steel, Zinc Plated |
| Flammability | Rated V-0 per UL 94 |
| Cord-Clamp | Nylon |
| Blades/Contacts | Solid Brass |
| Feature | Power Interrupting |
| Temperature Rise | Max 30C after 50 cycles OL at 150 percent rated current |
| Torque Range | 14-16 in-lbs |
| cULus | Listed |
| Interior Material | Phenolic |
| Grounding | Grounded |
| Terminal Accom. | 12-4 AWG |
| Grounding Screw | Brass 8-32 |
| Terminal Screws | Brass 8-32 |
| Line Contacts | Brass |
| Operating Temperature | -402°C to 1052°C |
| Current Interrupting | Certified for current interrupting at full rated current |
| Dielectric Voltage | Withstands 2000V per UL498 |
| Terminal Type | Screw |
| Amperage Rating | 20/30 |
| Temperature Rating | -40 to 105 |
| Grade | Industrial/Hospital |
| Package Quantity | 1 |
