Este dispositivo combinado de interruptor incluye un tomacorriente 5-20R y un puerto USB, con luz indicadora y alarma. Ideal para cargar dispositivos electrónicos y controlar la iluminación de forma práctica y segura.
| Color | Light Almond |
|---|---|
| Wiring Method | Back/Side Wired |
| Type | Type A/A Duplex Receptacle |
| Width | 1.7 in |
| Length | 2-1/4 in |
| Height | 4 in |
| Voltage | 125 VAC |
| Depth | 1.7 in |
| Features | Tamper Resistant |
| Grade | Residential/Commercial Specification Grade |
| Size | 4.04 in H x 1.73 in W x 1.68 in D |
| Application | Residential / Commercial |
| Grounding | Grounded |
| Horsepower Rating | 20A-1 HP |
| Product Type | Outlet/USB Combo |
| UL 498 | Yes |
| Terminal ID | Brass-Hot Black-Hot White-Neutral Green-Gnd |
| Flammability | Rated V-0 per UL 94 |
| Torque Range | 14 "- 18 in.-lbs |
| Strap Material | Steel |
| Cover Material | Thermoplastic |
| NEMA | 5-20R |
| Terminal Accom. | 14-12 AWG |
| Termination | Back, Side |
| Body Material | Thermoplastic |
| Amperage | 20 A |
| UL 1310 | Yes |
| Operating Temperature | -10°C to 40°C |
| Listed | cCSAus |
| Ratings | 20A-125V |
| Number of USB Ports | 2 |
| Product Name | Combination Devices |
| Current Rating | 20 A |
| Certifications & Standards | cCSAus, NOM: 057, FCC Part 15: Class B |
| Compatibility | Tablet PC, Smartphone, Cellular Phones, Gaming Devices, e-Readers, Digital Cameras |
| Product Material | Steel, Thermoplastic |
| USB | Yes |
| Form Factor | Wall Mountable |
| Voltage Rating | 120 V AC |
| Product Color | Light Almond |
| Receptacles Detail | 2 x NEMA 5-20R |
| Environmental Conditions | -10 to 40 deg C Operating Temperature |
| USB Type | 2.0 Type A |
| USB Rating | 3.6 A @ 5 VDC |
| Electrical Ratings | 20 A, 125 VAC, 1 hp |
| Wire Size | 14 to 12 AWG |
| Mounting | Wall Mount |
| Package Quantity | 1 |
