DIMMER SWITCH ILLUMATECH FAN SPD CNTL 1.5A WHT IV LA
| Color | White, Ivory, Light Almond |
|---|---|
| Voltage | 120 VAC |
| Switch Type | Single-Pole |
| Protection | Radio/TV Filter |
| Wallplate | Order Separately |
| Preset | Yes |
| Standards and Certifications | CSA, UL |
| Load Type | Fan |
| Color Change Kit | IPQFK Series |
| Ordering Notes | Includes Ivory, White and Light Almond Color Kits |
| Style Name | IllumaTech |
| Feature | Quiet Step |
| Load Rating | 1.5 Amp |
| Available Color Kits | Ivry-I Wht-W Light Almond-T Gry-G Blk-E Brwn-B |
| Light | LED Locator |
| Type | Electro-Mechanical |
| Amperage Rating | 1.5 A |
| Number of Poles | 1 |
| Environmental Conditions | 20 to 90 % (Relative Humidity Non-Condensing);Flammability (Rated V-2 per UL94) |
| Frequency Rating | 60 Hz |
| Height | 4.44 in |
| Application | Commercial |
| Mounting | Wall |
| Size | 4.15 H x 2.12 W x 1.41 D in |
| Width | 2-1/2 in |
| Operating Temperature | 32 to 130 deg F |
| Length | 2.81 in |
| Standard | UL Listed (E-31373), CSA Certified (LR-3413) |
| Package Quantity | 1 |
