Electrical Connector Assembly 16 Series Fml Plg 2 0 - 4 0 2 S.S. Gry
| Type | Cam-Type |
|---|---|
| Terminal Connection | Double Set Screw |
| Male/Female | Male |
| Current Rating | 400 A |
| NEMA Rating | Type 3R |
| Cable Range | 2/0 to 4/0 AWG |
| Standards | 1691, 508 to 35k A / 600V Short Circuit Current Rating |
| Conductor Material | Brass |
| Color | Gray |
| Width | 11 in |
| Length | 8 in |
| Application | Sports, Entertainment, Movie Industry, Theme Parks and Carnival Equipment, Concert Venues and C |
| Height | 7-1/4 in |
| Standard | UL 1691 |
| Number of Poles | 1 |
| Package Quantity | 1 |
