Este receptáculo hembra de panel de 90 grados de la Serie 17 de Leviton es ideal para aplicaciones eléctricas profesionales. Fabricado con materiales de alta calidad, garantiza un rendimiento fiable y duradero.
| Type | Cam Type Female Taper Nose |
|---|---|
| Series | 17 Series |
| Terminal Connection | Threaded Stud |
| Male/Female | Female |
| Current Rating | 690 A |
| Voltage Rating | 600 V |
| Color | Blue |
| Contact Material | Brass |
| Material | Santroprene TPV |
| Cable Range | 250 to 750MCM AWG |
| Application | Sports, Entertainment and Movie Industry, Welding and Construction Sites, Theme Parks and Carni |
| Height | 4-1/2 in |
| Width | 12 in |
| Length | 9 in |
| Wire Size | 250 to 750 |
| Mounting Type | Panel |
| Amperage Rating | 690 A |
| Specifications | Industrial Grade |
| Dimensions | 4.48 in Dia x 7.96 in L |
| Conductor Range | 250-750 MCM |
| Number of Poles | 1 |
| Package Quantity | 1 |
