Este receptáculo hembra de color naranja es compatible con cables de calibre 2/0-4/0 y cuenta con nariz cónica para una conexión segura.
| Item | Receptacle |
|---|---|
| Series | 16 |
| Terminal Connection | Double Set Screw |
| Male/Female | Female |
| Current Rating | 400 A |
| Voltage Rating | 600VAC/250VDC |
| NEMA Rating | 3R, 4X, 12 |
| Standards | UL & CSA |
| Amps AC/DC | 300 AC/DC |
| Fits | Male Plug |
| Single Pole Device Style | Taper Nose |
| Cable Range | 2/0 to 4/0 |
| Conductor Material | Solid Brass |
| Mounting | Screw Mount |
| Material | Thermoplastic Elastomer |
| Color | Orange |
| Length | 9-1/4 in |
| Application | Commercial, Navy Shipbuilding, Sports, Entertainment, Movie Industry, Welding, Construction Sit |
| Height | 7-1/4 in |
| Number of Poles | 1 |
| Amperage Rating | 400 A |
| Package Quantity | 1 |
