Conector macho color rojo con nariz cónica y capacidad para 300Ac/Dc. Producto de alta calidad y resistencia fabricado por Leviton.
| Item | Connector |
|---|---|
| Type | 16 Series Single Pole Cam |
| Series | 15 |
| Terminal Connection | Single Pin |
| Male/Female | Male |
| Current Rating | 400 A |
| Voltage Rating | 600VAC/250VDC |
| NEMA Rating | 3R, 4X, 12 |
| Material | Thermoplastic Elastomer |
| Single Pole Device Style | Taper Nose |
| Color | Red |
| Mounting | Screw Mount |
| Standards | UL & CSA |
| Amps AC/DC | 300 AC/DC |
| Conductor Material | Solid Brass |
| Cable Range | 2/0 to 4/0 |
| Fits | Female Plug |
| Height | 7-1/4 in |
| Length | 8 in |
| Width | 11 in |
| Contact Material | Brass |
| Mounting Type | Panel |
| Dimensions | 2.28 in L x 4.27 in W |
| Number of Poles | 1 |
| Housing Material | Santoprene TPV |
| Amperage Rating | 400 A |
| Connection Type | Screw |
| Wire Size | 1/0 to 4/0 AWG |
| Package Quantity | 1 |
