Este receptáculo macho de Leviton en color naranja es capaz de soportar corrientes de 2-4/0 y voltajes de 600V CA / 250V CC. Ideal para aplicaciones industriales y comerciales.
| Item | Receptacle |
|---|---|
| Type | Cam-Type |
| Series | 16 |
| Terminal Connection | Double Set Screw |
| Male/Female | Male |
| Current Rating | 400 A |
| Voltage Rating | 600VAC/250VDC |
| NEMA Rating | 3R, 4X, 12 |
| Material | Thermoplastic Elastomer |
| Standards | UL & CSA |
| Color | Orange |
| Cable Range | 2 to 4/0 |
| Fits | Female Plug |
| Amps AC/DC | 400 AC/DC |
| Mounting | Screw Mount |
| Conductor Material | Solid Brass |
| Single Pole Device Style | Taper Nose |
| Length | 5-1/2 in |
| Height | 7-1/4 in |
| Width | 10 in |
| Application | Motor, Generator Splices, Mining, Construction Sites, Commercial, Navy Shipbuilding, Repair, Ot |
| Standard | UL: 1691 |
| Package Quantity | 1 |
