Receptacle, 15 A Amps, 125VAC, Decorator Duplex Outlet, 5-15R, Brown
| Item | Receptacle |
|---|---|
| Outlet Type - Plugs and Receptacles | Decorator Duplex |
| Application Environment | Residential Grade |
| Amps - Plugs and Receptacles | 15 A |
| Voltage - Plugs and Receptacles | 125VAC |
| NEMA Receptacle Configuration - Plugs and Receptacles | 5-15R |
| Color - Plugs and Receptacles | Brown |
| Wiring Method - Plugs and Receptacles | Side, Push |
| Number of Poles | 2 |
| Number of Wires | 3 |
| Type | Duplex Receptacle |
| Material | Thermoplastic (Body and Face) |
| Item - Plugs and Receptacles | Duplex Receptacle |
| Standards | Class 6233-01, CSA C22.2 No. 42 File E152105, CSA Certified, UL 498 File E13399 |
| Voltage | 125 VAC |
| Phase | Single |
| Includes | Strap Material |
| Sub-Category | Duplex Receptacles |
| Wiring Method | Back, Side |
| Color | Brown |
| Grade | Federal Specification |
| Resistance Properties | Impact Resistant |
| Housing Material | Thermoplastic |
| Receptacle Type | Decorator Duplex |
| Minimum Operating Temperature | -40 deg F |
| NEMA Receptacle Configuration | 5-15R |
| Current Rating | 15 A |
| Overall Depth | 1.1 in |
| Polarized | No |
| NEMA Enclosure Rating | Not Rated |
| Hazardous Location Specification | Not Applicable |
| Voltage Rating | 125V AC |
| Includes Mounting Hardware | Yes |
| Market | Residential |
| Maximum Operating Temperature | 140 deg F |
| Mount Hole Center-to-Center Height | 3.3 in |
| UL 94 Flammability Rating | V-2 |
| GFCI | No |
| Number of Outlets | 2 |
| Housing Color | Brown |
| Connection Orientation | Straight |
| Face Plate Height | 2.8 in |
| Wire Connection Type | Screw Terminals |
| Mount Type | Flush |
| Face Plate Width | 1-1/2 in |
| Cover Type | No Cover |
| Grounding | Grounded |
| NOM Certified | 57 |
| Operating Temperature | -40°C to 60°C |
| CSA | Certified |
| Torque Range | 14 - 18 in.-lbs |
| Body Material | Thermoplastic |
| Amperage | 15 A |
| NEMA | 5-15R |
| UL 498 | File E13399 |
| Pole | 2 |
| UL Listed | File E13393 |
| Face Material | Thermoplastic |
| CSA C22.2 No. 42 | File 152105; Class 6233-01 |
| Termination | Quickwire Push-In & Side |
| Wire | 3 |
| Strap Material | Steel |
| Package Quantity | 1 |
