Receptacle, 20 A Amps, 120/208VAC, Flush Mount, 18-20R, Black
| Item | Receptacle |
|---|---|
| Item - Plugs and Receptacles | Receptacle |
| Application Environment | Industrial |
| Mounting Type - Plugs and Receptacles | Flush |
| Amps - Plugs and Receptacles | 20 A |
| Voltage - Plugs and Receptacles | 120/208VAC |
| NEMA Receptacle Configuration - Plugs and Receptacles | 18-20R |
| Color - Plugs and Receptacles | Black |
| Wiring Method - Plugs and Receptacles | Side |
| Number of Poles | 4 |
| Number of Wires | 4 |
| Color | Black |
| Standards | ANSI C73, CSA C22.2 No. 42 File E152105, NEMA WD-6, UL 498 File E13399 |
| Wiring Method | Side |
| Voltage | 120/208 VAC |
| Material | Nylon (Body and Face) |
| Sub-Category | Locking Receptacles |
| Phase | Three |
| Wire Connection Type | Screw Terminals |
| Receptacle Type | Single |
| Connection Orientation | Straight |
| Polarized | No |
| Number of Outlets | 1 |
| NEMA Enclosure Rating | Not Rated |
| Voltage Rating | 120/208V AC |
| Minimum Operating Temperature | -40 deg F |
| Includes | Grounding Clip |
| Hazardous Location Specification | Not Applicable |
| UL 94 Flammability Rating | V-2 |
| Mount Type | Flush |
| Current Rating | 20 A |
| Contact Material | Brass |
| Housing Material | Nylon |
| Housing Color | Black |
| Grounding | Non-Grounded |
| Includes Mounting Hardware | Yes |
| Grade | Federal Specification |
| Cover Type | No Cover |
| GFCI | No |
| Market | Industrial |
| NEMA Receptacle Configuration | 18-20R |
| Maximum Operating Temperature | 140 deg F |
| Wire | 4 |
| Operating Temperature | -40°C to 60°C |
| Strap Material | Galvanized Steel |
| ANSI | C-73 |
| Pole | 4 |
| Face Material | Nylon |
| CSA C22.2 No. 42 | File 152105 |
| Amperage | 20 A |
| UL498 | File E13399 |
| NEMA | WD-6 |
| Dielectric Voltage | Withstands 2000V per UL498 |
| Terminal ID | Brass-Hot, Green-Ground, Silver-Neutral |
| Flammability | Rated V-2 per UL 94 |
| Screw Terminal Torque | 14 in-lbs |
| Line Contacts | Brass |
| Terminal Accom. | Up to 4 AWG |
| Body Material | Nylon |
| Current Limiting | Full Rated Current |
| Temperature Rise | Max 30C after 50 cycles OL at 150 percent rated current |
| Package Quantity | 1 |
