Interruptor de palanca 20A 120 277V de 3 vías con plomo blanco.
| Body Material | Thermoplastic |
|---|---|
| Mounting | Box |
| Height | 10 in |
| Color | White |
| Connection | Wire Lead |
| Voltage | 120/277 VAC |
| NEMA | WD-1 & WD-6 |
| Actuator Material | Thermoplastic |
| UL Fed Spec WS896E | File #E7458 |
| Terminal Leads | 6", #12 AWG THHN |
| Cover Material | Urea |
| Grounding Leads | 6", #12 AWG THHN |
| Lead Identification | Leads identified in accordance with UL 498 (black, white & green) |
| Terminal ID | Brass-Hot Black-Hot White-Neutral Green-Gnd |
| Contacts | Silver-Cadmium .031 Thick |
| Function | 3 Way |
| Torque Range | 12-14 inch pounds |
| ANSI | C-73 |
| Base Material | Urea |
| Amperage | 20 A |
| Max. Amperage | 12 A |
| Device Type | Toggle Switch |
| Termination | Pre-Wired Leads |
| Dielectric Voltage Withstand | 1500V minimum |
| CSA C22.2 No. 111 | File #152105 |
| Mounting Strap | Steel |
| UL Standard | UL 20 |
| Temperature Rise | Maximum 30 degress C rise |
| Flammability | Rated V-2 per UL 94 |
| Mounting Screws | Triple Combination Head, Steel |
| Maximum Working Voltage | 120/277 VAC as rated |
| Strap Material | .048" Thick Galvanized Steel |
| HP Rating | 1/2HP-120V 2HP-240V-277V |
| Grade | Extra Heavy-Duty Industrial Specification Grade |
| Operating Temperature | -40°C to 65°C |
| Grounding | Self-Grounding |
| Terminal Accom. | 14-10 AWG |
| Terminal Type | Lead Wire |
| Enclosure | NEMA WD-1, WD-6 |
| Power Rating | 0.5 HP, 2 HP |
| Actuator | Toggle |
| Environmental Conditions | Flammability (Rated V-2 per UL94) |
| Dimensions | 46 in H x 1.31 in W x 13 in D |
| Number of Poles | 1 |
| Application | Commercial |
| Standard | NEMA (WD-1 and WD-6);ANSI (C-73);NOM (057);CSA C22.2 No. 111 (File 152105);UL Fed Spec WS896E (File E7458);UL Standard (UL 20);RoHS Compliant |
| Length | 11-3/4 in |
| Package Quantity | 1 |
