Midget Fuse, LLNRK Series, Time-Delay, 200A, 250V AC, Non-Indicating
| Series | LLNRK |
|---|---|
| Speed | Time Delay |
| Amps | 200A |
| AC Voltage Rating | 250V AC |
| Visual Indication | Non-Indicating |
| Interrupt Rating | 200kA at 250VAC, 20kA at 125VDC |
| Body Style | Blade |
| Diameter | 1-19/32 in |
| Length | 7-1/8 in |
| Body Material | Melamine |
| Equivalent Brand and Series | Bussmann LPN-RK, Edison LENRK, Littelfuse LLNRK, Mersen A2D-R |
| Fits Fuse Block Style | Rejection |
| Compatible Fuse Block Series | LFR |
| DC Voltage Rating | 125V DC |
| Item | Midget Fuse |
| Class | RK1 |
| Functionally Equal To | Bussmann LPN-RK, Edison LENRK, Mersen/Ferraz Shawmut A2D-R |
| Standards | CE, UL 248-12 Class RK1, CSA Certified, QPL-W-F-1814 |
| Element | Dual |
| Equivalent Series | A2D-R, LENRK, LLNRK, LPN-RK |
| Opening | Slo-Blo/Time Lag (T)/Time Delay |
| Package Quantity | 1 |
