Open Fuse Block, J UL Class, 1 Poles, 0 to 30A Amp Range, 600V AC/DC Volt Rating
| Item | Open Fuse Block |
|---|---|
| UL Class | J |
| Series | LFJ |
| Number of Poles | 1 |
| Amp Range | 0 to 30A |
| Voltage Rating | 600V AC/DC |
| Connector Type | Box Lug |
| Mounting Style | Bolt-Down; DIN Rail |
| Visual Indication | Indicating |
| Spring Reinforced Clip | Yes |
| Fuse Block Design | Open |
| Body Material | Thermoplastic |
| Height | 3.7 in |
| Wire Range | 14 AWG to 6 AWG |
| Fits Fuse Type | Industrial |
| Fuse Type | Class J |
| Standards | UL94 V-0, UL Listed, CSA Certified, RoHS Compliant, Lead (Pb) Free, REACH Compliant |
| Features | Phenolic Blocks Have Side Barriers for Isolation |
| Length | 1.15 in |
| Width | 1.95 in |
| Fits Fuse Block Style | Non-Rejection |
| Package Quantity | 1 |
