UL Class Fuse, RK1 Class, LLSRK Series, Time-Delay, 200A, 600V AC, Non-Indicating
| Class | RK1 |
|---|---|
| Series | LLSRK |
| Speed | Time-Delay |
| Amps | 200A |
| AC Voltage Rating | 600V AC |
| DC Voltage Rating | 300V DC |
| Visual Indication | Non-Indicating |
| Interrupt Rating | 200kA at 600V AC, 20kA at 300V DC |
| Body Style | Blade |
| Body Material | Melamine |
| Length | 9-5/8 in |
| Diameter | 1-27/32 in |
| Equivalent Brand and Series | Bussmann LPS-RK, Edison LESRK, Littelfuse LLSRK, Mersen A6D-R |
| Equivalent Series | A6D-R, LESRK, LLSRK, LPS-RK |
| Fits Fuse Block Style | Rejection |
| Compatible Fuse Block Series | LFR |
| Item | UL Class Fuse |
| Standards | CE, UL 248-12 Class RK1, CSA Certified, QPL-W-F-1814 |
| Element | Dual |
| Functionally Equal To | Bussmann LPS-RK, Edison LESRK, Mersen/Ferraz Shawmut A6D-R |
| Opening | Slo-Blo/Time Lag /Time Delay |
| Package Quantity | 1 |
